The F-35A Lightning II is a fifth-generation fighter combining advanced aerodynamics, survivability in high-threat environments and an enhanced ability to provide pilots and allied assets across operational domains with robust situational awareness.



The F-35 is the result of the Joint Strike Fighter (JSF) program to develop a single-engine, stealthy, multi-role fighter to replace an aging fleet of mission-dedicated airframes: the F-16 Fighting Falcon and A-10 Thunderbolt II for the Air Force and the F/A-18 Hornet and AV-8B Harrier II for the Navy and Marine Corps.

Although separate airframe variants were designed to meet specific needs of the various military services, all F-35 variants are primarily designed to infiltrate contested airspace, accurately deliver guided and conventional munitions, and collect, process and disseminate real-time reconnaissance while maintaining robust air-to-air combat capability at speeds above Mach 1.

Military and budgetary benefits of international cooperation are well represented in the F-35 program. Partner nations including the U.S., U.K., Canada, Netherlands, Italy, Turkey, Denmark, Norway and Australia, are highly involved in the aircraft’s ongoing development. The F-35 has also been sold to Israel, Japan and South Korea.

Use of a common weapons system among allies promotes an operational familiarity during coalition partner training and combat, while reducing the cost, time, training, manning and research and development of integrating dissimilar airframes of those allied nations.

The Royal Australian Air Force, has committed to obtaining 72 F-35A aircraft to form three operational squadrons at RAAF Base Williamtown and RAAF Base Tindal, and a training squadron at RAAF Base Williamtown. The RAAF is expected to take delivery of its first operational F-35As in December 2018.

DEVELOPMENT

After winning the JSF design competition, $750 million contracts to build prototypes were awarded in 1997 to both Lockheed Martin for it’s X-35, and Boeing, for its X-32.

Boeing’s entry incorporated the requirements of all the services into one short take-off and vertical landing (STOVL) airframe with thrust being vectored through nozzles, as with the existing Harrier.

Lockheed Martin proposed to produce three airframe variants, one for each service: the conventional take-off and landing (CTOL) F-35A for the Air Force’s long runways; the STOVL version, the F-35B, for U.S. Marine Corps and British navy and air force; and the F-35C for U.S. Navy carrier-born operations.

In the end, the Department of Defense determined the X-35B version, with a separate vertical-lift fan behind the cockpit, outperformed the Boeing entry and awarded the overall JSF contract to Lockheed Martin.

The first F-35A test aircraft purchased by the Air Force rolled off the production line in 2006. The Air Force took delivery of its first production F-35As at Eglin Air Force Base, Florida, in 2011 to begin pilot and maintainer training and in 2014 the 58th Fighter Squadron was the first to become a complete F-35A squadron.

After years of testing weapons separation, operational integration and aerial refueling, the Lightning II met its targets for initial operational capability when it was declared “combat ready” in August of 2016 by Gen. Hawk Carlisle, commander of Air Combat Command.

FEATURES AND DEPLOYMENT

Air Force units that operate the F-35A now include:

  • The 461st Flight Test Squadron and 31st Test and Evaluation Squadron at Edwards AFB, California.

  • The Integrated Training Center for pilots and maintainers at Eglin AFB, Florida.

  • The 388th Fighter Wing and 419th Fighter Wing at Hill AFB, Utah.

  • The 56th Fighter Wing at Luke AFB, Arizona.

  • The 422nd Test and Evaluation Squadron at Nellis AFB, Nevada.


The F-35 serves as an unparalleled force multiplier because its advanced sensors and datalinks share information and situational awareness not just between fifth- and fourth-generation U.S. and allied aircraft, but also between coalition land, sea and space assets.

This “operational quarterback” is also proving to pack a nasty ground attack and individual air-to-air combat capability.

During the large-scale combat training exercise, Red Flag 17-1, held at Nellis AFB in the spring of 2017, F-35As participated in multi-aircraft sorties in a highly-contested airspace. Air Force leadership and pilots reported F-35As destroyed multiple ground targets without being detected in the airspace and earned a stellar 20:1 kill ratio in air-to-air combat scenarios.

Despite the impressive individual performance, Air Force Chief of Staff Gen. David Goldfein stresses the F-35 is best thought of as an integral component of the Air Force’s overall warfighting capability.

During a symposium at the Center for Strategic and International Studies in February of 2017, Goldfein was asked to compare the F-35’s capability versus advanced Chinese aircraft like the J-20 and the J-31.

“I hope, over time, we can evolve our discussion from platform v. platform, which I would argue is a 20th Century discussion, to a network versus network,” Goldfein said. “Its not about what the F-35 or the J-20 or the F-22 or the J-31 can actually do in a one versus one… it’s an interesting conversation, but its not very compelling because we are never going to have the F-35 in there by itself, ever.

“What really counts is we are going to bring a network, a family of systems to bear on the enemy. That’s going to be an F-35 that’s there with an F-22, that’s there with an F-18, that’s there with a space capability being fed into the cockpit, that’s there with cyber capabilities, that’s there with a multitude of ISR, that’s there with a submarine force. We’re going to bring multi-domain, multi-component capabilities and we’re going to bring coalition capabilities.

“As we do today, in the future, we are going to be able to achieve decision speed and maneuver forces from all domains and create so many dilemmas for the enemy that, that in itself, will become a deterrent value,” Goldfein said.

Partner nations who have purchased the airframe, the U.S., United Kingdom, Canada, Netherlands, Italy, Turkey, Denmark, Norway and Australia, are highly involved in the aircraft’s ongoing development. As such, the F-35 program represents a model of the military and budgetary benefits of international cooperation. The F-35 has also been sold to Israel, Japan and the Republic of South Korea.

Use of a common weapons system among allies promotes an operational familiarity during coalition partner training and combat, while reducing the cost, time, training, manning and research and development of trying to integrate dissimilar airframes of those allied nations.

DID YOU KNOW?

  • The F-35A CTOL variant is flown by the air forces of the Netherlands, Australia, Japan and Italy.

  • The three F-35 variants are manufactured in Fort Worth, Texas, Cameri, Italy, and Nagoya, Japan, with 300,000 parts from 1,500 suppliers worldwide.

  • The F-35 software has more lines of code than the Space Shuttle.

  • An F-35’s pilot wears a helmet that has inputs necessary for situational awareness projected onto the interior of the visor: airspeed, heading, altitude, targeting information and warnings. It also projects imagery from around the aircraft, via infrared cameras, onto the visor, allowing the pilot to “look through” the bottom of the aircraft.

  • The F-35 Lightning II is named after the famous WWII fighter, the twin-engine P-38 Lightning. The U.S.’ leading air combat pilot of WWII, Maj. Richard I. Bong, scored all of his 40 victories flying the P-38.
